The PLZW-rapid is a lifting point distinguished by its innovative features. It allows for quick and easy assembly: simply press the button to unlock the threaded plates, insert the lifting point into the threaded hole, release the button, and tighten the screw by hand. The locking indicator must then be checked to ensure the green ring is visible, confirming the lifting point is ready for use.
Designed for maximum flexibility, the PLZW-rapid is 360° rotatable, allowing for adjustment in the direction of the load, and the ring can be folded 180° for added versatility. The screw is made of rust-resistant stainless steel, while the sleeve protects the contact surface of the load. Each unit features an individual serial number for traceability and offers a five-fold safety factor against breakage
- Material: Alloy steel, stainless steel
- Marking: According to standard, CE-marked, WLL, thread size and an individual serial number.
- Temperature range: -20°C up to +200°C
-
Standard:
EN 1677-1
except grade/WLL
- Safety factor: 5:1
