Intended for attaching of wire rope where switching often occur, e.g. blocks of mobilecranes, or to be able to adjust the length of the wire rope. See recommended assembly to get correct results.
The wedge socket is delivered complete with wedge, bolt, nut and cotterpin.

2 surface finishes available:

  • Model OWS B : blue painted.
  • Model OWS BGALV : Hot dipped galvanized.
  • Material: Quenched and tempered cast steel
  • Marking: CE-marked
  • Temperature range: - 40°C to + 110°C - Use at higher temperatures possible with reduction of WLL.
  • Finish: Blue painting or hot dipped galvanized
  • Note: The efficiency of a 6 and 8 strand wire rope/wedge socket connection is 80% of the minimum breaking load of the wire but limited to the minimum breaking load of the socket (MBL).
Select a row from the table below, then click the add to quote button
Part Code MBL For wire Ø
mm
A
mm
B
mm
C
mm
øP
mm
T
mm
TL
mm
TB
mm
W
mm
Weight CAD
10.20OWS0.25BG 8 7-8 110 18 36 16 9 128 51 18 0.8
10.20OWS0.5BG 12 9-10 145 23 46 21 11 168 63 21 1.7
10.20OWS01BG 20 11-13 157 29 57 25 12 185 67 25 2.1
10.20OWS01B 20 11-13 157 29 57 25 12 185 67 25 2.1
10.20OWS02BG 25 14-16 190 35 70 30 15 225 85 31 4
10.20OWS02B 25 14-16 190 35 70 30 15 225 85 31 4
10.20OWS03B 40 18-19 210 40 80 35 16 250 95 38 7
10.20OWS03BG 40 18-19 210 40 80 35 16 250 95 38 7
10.20OWS04B 55 20-22 252 48 95 41 18 300 110 44 10
10.20OWS04BG 55 20-22 252 48 95 41 18 300 110 44 10
10.20OWS05B 75 23-26 298 55 110 51 22 353 128 51 15
10.20OWS05BG 75 23-26 298 55 110 51 22 353 128 51 15
10.20OWS06B 90 27-29 322 65 130 57 25 387 142 57 21
10.20OWS06BG 90 27-29 322 65 130 57 25 387 142 57 21
10.20OWS07B 110 30-32 350 73 146 63 28 423 155 63 31
10.20OWS07BG 110 30-32 350 73 146 63 28 423 155 63 31
10.20OWS08B 125 34-36 400 74 148 64 28 474 160 70 37
10.20OWS08BG 125 34-36 400 74 148 64 28 474 160 70 37
10.20OWS09BG 150 37-39 450 80 142 70 30 530 177 77 51
10.20OWS09B 150 37-39 450 80 142 70 30 530 177 77 51
10.20OWS10B 170 40-42 500 87 160 76 33 587 187 76 64
10.20OWS10BG 170 40-42 500 87 160 76 33 587 187 76 64
