• Not for lifting

General: Chain for different applications.


  • Material: Grade 2.
  • Marking: According to standard
  • Finish: 3-4,5 mm zink-platined, 5- mm hot-dip galvanized.
  • Standard: DIN 763
  • Warning: Not for lifting.
  • Grade: 2
Hlx_225mm
HLM_e_225mm
Select a row from the table below, then click the add to cart button
Part Code Chain diameter
mm
Min. breaking force
kN
Length D
mm
E
mm
H
mm
Weight
kg/m
11.60763030ER50 3 3,2 50 3 26 6 0,15
11.60763040ER50 4 6 50 4 32 8 0,27
11.60763050ER30 5 10 30 5 35 10 0,43
11.60763060ER30 6 14 30 6 42 12 0,63
11.60763080ER15 8 22 15 8 52 16 1,1
11.60763100ER15 10 40 15 10 65 20 1,8
*Please note that this product is sold only in rolls.
