Design: Closed, slidable wear protection for both chain and wire rope.

  • Material: Polyurethane.
  • Note: Delivered in standard length of 2 meters.
Stobitex_chain_and_rope_protection_pic
CPP illu
Stobitex_chain_and_wire_protection_drw
Select a row from the table below, then click the add to quote button
Art No Outside axb (mm) Inside Ø (mm) For gr 10 chain mm Weight
kg/m
CAD
12.4000203010 22 x 22 12 0.5
12.4000203020 24 x 24 14 0.65
12.4000203040 28 x 28 18 0.75
12.4000203050 30x30 20 0.8
12.4000203060 32 x 32 22 6 1
12.4000203070 36 x 36 26 7 1.2
12.4000203080 38 x 38 28 8 1.25
12.4000203090 42 x 42 32 8 1.5
12.4000203100 45 x 45 35 10 1.65
12.4000203110 52 x 52 42 10 2.05
12.4000203120 55 x 55 45 13 2.35
12.4000203130 60 x 60 50 13 2.65
12.4000203140 73 x 73 63 16 3.4
Double version can be supplied on request
