Heavy duty clamp for safe lifting and transporting of steel (oil) drums. Single clamp application on empty or filled sealed drums. Filled open drums should be lifted by use of two clamps with a two leg chain sling.
Features:
- With automatic locking mechanism
- Lightweight design for easy handling
- Tough quality heavy duty welded shell body
- Maintenance-friendly, easy to exchange parts which are available upon request
- Delivered with certificate.
- Material: Alloy steel
- Marking: According to standard, Type, serial number, WLL, Jaw opening and CE marking.
- Temperature range: - 40°C up to +100°C.
- Standard: EN 13155
Select a row from the table below, then click the add to quote button
Download CAD
Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.
Get CAD
Download
