Design: Round sling covered with extra protection sleeve and provided with strengthen eye in each end.


Stretch with working load: 2-3%.

Length tolerance: Nominal length ±2%.

  • Material: Polyester. Resistant to most acids but not strong alkalizes.
  • Marking: The slings are provided with a blue label with manufacturer’s symbol, working load limit (WLL), length, CE marking and a label with handling instruction.
  • Temperature range: app. -40° - +100°C.
  • Standard: EN 1492-2
  • Safety factor: 7:1.
Rss-1_e_225mm_2
length_90_e_225mm_2
Select a row from the table below, then click the add to quote button
Art No WLL
Ton
Colour WLL basket hitch 0º (ton) WLL basket hitch 0º-45º (ton) WLL basket hitch 45º-60º (ton) Working load limit (WLL) in tons Choked hitch
RSS01 1 violet 2 1,4 1 0,8
RSS02 2 green 4 2,8 2 1,6
RSS03 3 yellow 6 4,2 3 2,4
RSS04 4 gray 8 5,6 4 3,2
RSS05 5 red 10 7 5 4
RSS06 6 brown 12 8,4 6 4,8
RSS08 8 blue 16 11,2 8 6,4
RSS10 10 orange 20 14 10 8
RSS12 12 orange 24 16,8 12 9,6
RSS15 15 orange 30 21 15 12
RSS20 20 orange 40 28 20 16
RSS25 25 orange 50 35 25 20
RSS34 34 orange 68 47,6 34 27,2
Other dimensions, WLL and special length on request.
