Ropeblock

General: Intended for attaching of wire rope where switching often occur, e.g. blocks of mobilecranes, or to be able to adjust the length of the wire rope. See recommended assembly to get correct results.
Design: The wedge socket is delivered complete.

Marking house and wedge: Wire ø mm.

The dead end should have a length of 6 times the wire dia. with a minimum of 150mm.

  • Material: Cast alloy steel with high mechanical properties.
  • Finish: Blue painted or hot dip galvanized (OWS 0.25 to 0.5 is standard delivered with galvanized finish) / Pin or bolt.
  • Note: The efficiency of a 6 and 8 strand wire rope/wedge socket connection is 80% of the minimum breaking load of the wire but limited to the minimum breaking load of the socket (MBL).
OWS 3 P
wedge_socket_225mm
Select a row from the table below, then click the add to quote button
Part Code Code MBL
t
Rope Ø
mm
TB
mm
TL
mm
Finish A
mm
B
mm
C
mm
Ø P
mm
T
mm
W
mm
Weight
kg
CAD
10.20OWS0025B OWS 0.25 B 8 7-8 62 128 110 18 36 16 9 18 0.8
10.20OWS0025P OWS 0,25 P 8 7-8 51 128 G 110 18 36 16 9 18 0.8
10.20OWS005B OWS 0.5 B 12 9-10 75 168 145 23 46 21 11 21 1.7
10.20OWS005P OWS 0,5 P 12 9-10 63 165 G 145 23 46 21 11 21 1.7
10.20OWS01B OWS 1 B 20 11-13 80 175 146 29 57 25 12 25 2.1
10.20OWS01P OWS 1 P 20 11-13 67 174,5 G 146 28,5 57 25 12 25 2.1
10.20OWS02B OWS 2 B 25 14-16 96 211 176 35 70 30 15 31 4
10.20OWS02P OWS 2 P 25 14-16 85 211 G 176 35 70 30 15 31 4
10.20OWS03P OWS 3 P 40 18-19 95 250 G 210 40 80 35 16 38 7
10.20OWS03B OWS 3 B 40 18-19 107 250 210 40 80 35 16 38 7
10.20OWS04B OWS 4 B 55 20-22 123 285 238 48 95 41 18 44 10
10.20OWS04P OWS 4 P 55 20-22 110 285 G 237,5 47,5 95 41 18 44 10
10.20OWS05B OWS 5 B 75 23-26 138 330 275 55 110 51 22 51 15
10.20OWS05P OWS 5 P 75 24-26 128 330 G 275 55 110 51 22 51 15
10.20OWS06B OWS 6 B 90 27-29 160 375 310 65 130 57 25 57 21
10.20OWS06P OWS 6 P 90 27-29 142 375 G 310 65 130 57 25 57 21
10.20OWS07B OWS 7 B 110 30-32 165 423 350 73 146 63 28 63 31
10.20OWS07P OWS 7 P 110 30-32 155 423 G 350 73 146 64 28 63 31
10.20OWS08B OWS 8 B 125 34-36 185 474 400 74 148 64 28 70 37
10.20OWS08P OWS 8 P 125 34-36 160 474 G 400 74 148 64 28 70 37
10.20OWS09B OWS 9 B 150 37-39 201 530 450 80 142 70 30 77 51
10.20OWS09P OWS 9 P 150 37-39 177 530 G 450 80 142 70 30 77 51
10.20OWS10B OWS 10 B 170 40-42 209 587 500 87 160 76 33 76 64
10.20OWS10P OWS 10 P 170 40-42 187 587 G 500 87 160 76 33 76 64
10.20OWS11B OWS 11 B 225 43-48 237 650 550 100 186 89 39 89 96
10.20OWS11P OWS 11 P 225 43-48 215 650 G 550 100 186 89 39 89 96
10.20OWS12P OWS 12 P 280 49-52 244 745 G 640 105 205 95 46 101 130
10.20OWS12B OWS 12 B 280 49-52 263 745 640 105 205 95 46 101 130
10.20OWS13B OWS 13 B 360 54-58 298 785 660 125 250 108 54 114 180
10.20OWS13P OWS 13 P 360 54-58 275 785 G 660 125 250 108 54 114 180
10.20OWS14B OWS 14 B 425 60-68 330 970 835 135 270 121 60 127 275
10.20OWS14P OWS 14 P 425 60-68 300 970 G 835 135 270 121 60 127 275
10.20OWS15B OWS 15 B 460 72-76 380 1,150 1,000 150 300 133 76 146 440
10.20OWS15P OWS 15 P 460 72-76 355 1,150 G 1,000 150 300 133 76 146 440
10.20OWS16B OWS 16 B 625 81-86 397 1,250 1,100 150 300 140 79 159 510
10.20OWS16P OWS 16 P 625 81-86 375 1,250 G 1,100 150 300 140 79 159 510

Code: OWS xx P - Pin , OWS xx B - Bolt

Finish: P-Painted, G-Galvanized
