Patented safety-brake-clutch system.
Modular hoist design.
Simply and cost effective maintenance and repair.
Different chain qualities available.
Quick and safe change between single and double fall of chain.
Low voltage control with changeable components – no printed circuit boards.
- Power supply 400 V, 3 ph, 50 Hz
- Different voltage and frequency options available on request
- Protection class IP55
- Insulation class F
- 1.5 m standard control cable
. 3 m standard lifting height
- Different lifting height and control cable lengths available on request
- For lifting heights of more than 20 m the safe working load will be reduced by the chain weight
- STAR models 090/…, 091/…, 110/…
