Design: Forged according to standard DIN A 82101.



Proof: 2 x WLL.

  • Material: grade 3.
  • Marking: WLL, supplies code and grade.
  • Finish: Galvanized.
  • Safety factor: 4,5:1.
101_225mm
2929_lom_225mm
Select a row from the table below, then click the add to quote button
Art No Code WLL
Ton
Thread d1 D2 (mm) A (mm) C (mm) D (mm) Weight
kg
04.65106 106 0.6 M10 20 15 30 8,5 0.1
04.65107 107 0.9 M12 28 20 39 11 0.2
04.65108 108 1.5 M16 33 24 52 13 0.4
04.65109 109 2.4 M20 40 28 65 16 0.65
04.65110 110 3 M22 46 30 72 18 0.9
04.65111 111 3.7 M24 48 32 78 19 1.1
04.65112 112 4.8 M27 52 36 86 22 1.7
04.65113 113 6 M30 60 40 94 25 2.5
04.65114 114 7.5 M33 64 44 103 28 3.1
04.65115 115 9.4 M39 72 48 116 32 4.5
04.65116 116 12 M42 82 52 129 35 5.7
