WARNING! Not to be heat-treated.

  • Material: Alloy steel grade 8.
  • Marking: Code and grade.
  • Finish: Painted
  • Safety factor: 4:1.
  • Grade: 8
FH_new_225mm_2_[2]
FHm_new4_225mm
Select a row from the table below, then click the add to quote button
Part Code Code WLL
ton
D
mm
C
mm
L
mm
T
mm
k (mm) Weight
kg
CAD
04.57FH06 FH-6-8 1.12 50 10 95 15 24 0.6
11.10B701J FH-7/8-8 2 64 14,5 136 28,5 36 1.1
11.10B702J FH-10-8 3.15 78 18 166 36,1 44 2.1
11.10B703J FH-13-8 5.3 89 20 190 41 51 3.5
04.57FH16 FH-16-8 8 102 24 207 35 50 5.3
04.57FH20 FH-18/20-8 12.5 114 26 235 40 67 11
04.57FH22 FH-22-8 15 127 30 265 47 70 13
04.57FH26 FH-24/26-8 21.2 136 34 305 54 80 18
04.57FH32 FH-32-8 31.5 152 40 327 60 100 27

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.
