General: For lifting and transporting of thin sheets that deflect when being lifted. Compact shape and relatively low own weights, with a high lifting capacity. The Terrier TDH horizontal lifting clamps must always be used in pairs (or multiples thereof). Sold in pairs.




2).

  • Marking: Working load limit, jaw capacity and CE-marking.
  • Finish: Yellow painted.
  • Note: The lifting clamps are suitable for lifting and transporting of steel plates with a maximum hardness of 37 HRC (345 HB, 1166 N/mm
  • Safety factor: 5:1
TDH [new]
TDH_m2
TDH_m
Select a row from the table below, then click the add to quote button
Art No WLL
Ton
Jaw capacity (R) A (mm) B (mm) C (mm) D (mm) E (mm) F (mm) G (mm) H (mm) Weight
kg
16.01970100 1 0-15 167 140 65 10 100 22,5 15 13 3
16.01970200 2 0-35 235 180 80 20 115 26 15 13 8
16.01970400 4 0-50 310 235 130 35 130 40 20 25 20
16.01970600 6 0-50 310 235 130 35 130 40 20 25 20
