Advantages:
- Compact design
- Secured four times against breakage
- D-link swings 180°
- Weld-on shackle made of material S355JR according to EN 10025
- Material: Eye of alloy steel grade 8. Welding attatchment of steel St 52.
- Marking: WLL.
- Finish: Painted.
- Note: The surface that the lifting eyes shall be attached to shall be flat and tolerate the load it is going to be exposed to.
- Safety factor: 4:1.
- Grade: 8






Select a row from the table below, then click the add to cart button
kind of attachment |
|
|
|
|
|
|
|||||||||||
number of piece | 1 | 1 | 2 | 2 | 2 | 3 o. 4 | |||||||||||
inclination angle | 0° | 90° | 0° | 90° | 0°-45° | 45°-60° | 0°-45° | 45°-60° | |||||||||
Code | WLL ton | ||||||||||||||||
t | t | t | t | t | t | t | t | ||||||||||
TAPS 1 | 1,60 | 1,12 | 3,20 | 2,24 | 1,50 | 1,12 | 2,36 | 1,60 | |||||||||
TAPS 2 | 3,00 | 2,00 | 6,00 | 4,00 | 2,80 | 2,00 | 4,00 | 3,00 | |||||||||
TAPS 3 | 4,75 | 3,15 | 9,50 | 6,30 | 4,25 | 3,15 | 6,30 | 4,75 | |||||||||
TAPS 5 | 8,00 | 5,30 | 16,00 | 10,60 | 7,10 | 5,30 | 11,20 | 8,00 | |||||||||
TAPS 8 | 12,00 | 8,00 | 24,00 | 16,00 | 11,20 | 8,00 | 16,00 | 12,00 | |||||||||
TAPS 15 | 22,40 | 15,00 | 45,00 | 30,00 | 21,20 | 15,00 | 31,50 | 22,40 | |||||||||
TAPS 20 | 30,00 | 20,00 | 60,00 | 40,00 | 30,00 | 20,00 | 40,00 | 30,00 | |||||||||
TAPS 25 | 37,50 | 25,00 | 75,00 | 50,00 | 33,50 | 25,00 | 50,00 | 37,50 | |||||||||
TAPS 30 | 45,00 | 30,00 | 90,00 | 60,00 | 45,00 | 30,00 | 63,00 | 45,00 | |||||||||
TAPS 35 | 50,00 | 35,00 | 100,00 | 70,00 | 47,50 | 35,00 | 70,00 | 50,00 | |||||||||
TAPS 40 | 60,00 | 40,00 | 120,00 | 80,00 | 56,00 | 40,00 | 80,00 | 60,00 | |||||||||
TAPS 50 | 71,00 | 50,00 | 142,00 | 100,00 | 70,00 | 50,00 | 100,00 | 71,00 | |||||||||
TAPS 63 | 75,00 | 63,00 | 150,00 | 126,00 | 90,00 | 63,00 | 132,00 | 95,00 |
